Hinowa Lightlift 26.14 Spider Boom Lift Hire
25.7m Diesel or Electric Tracked Spider
The Hinowa Lightlift 26.14 is a tracked spider boom lift with a maximum platform height of 23.7-metres. It has a platform capacity of 230kg and a maximum working height of 25.7-metres, with an outreach of 13.75-metres. This spider boom is ideal for inspection, installation, cleaning, maintenance, and other work at heights. As it is available with either a diesel or lithium electric engine, you can use it for indoor and outdoor jobs.
The Hinowa Lightlift 26.14 is compact and narrow, so you can use it for access in very confined areas. The tracks also offer excellent traction across rough and sloped terrain. When in place, you can widen the tracks to 1.49-metres for extra stability, and you can lower the four folding outriggers for further support, even if the surfaces are different levels.
The articulating boom unfolds steadily from the stowed envelope, offering excellent reach and up-and-over access. You can rotate the jib 360° and rotate the basket 124° for unrestricted accessibility in the work field.
-
Capacity platform: 230kg Max. Working Height: 25.70m Max. Horizontal Working Outreach: 13.75m Max Working Horizontal Outreach Restricted Area: 9.75m Transport Length: 6.34m Transport Length Without Basket and Rotated Support: 5.98m Transport Height With Plates Installed: 1.98m Standard Basket Dimensions: 1335x690x1100mm Basket Rotation: 124°(+/-62°) Maximum Stabilization Angle: 16° Max Slope Allowed in Travel Mode: 16°/28.7% Total Weight: 4365kg Diesel - 4384 Lithium-ion Diesel Engine: Kubota D902 Electric Motor: 2.2kw-230V-50Hz / 2.2kw-110V-50Hz Engine Max. Travel Speed: 1.1 - 2 km/h Lithium-ion Powered: 7.6 KWh Max. Travel Speed - Lithium-ion Version: 0.7 - 1.2km/h Undercarriage Width Open/Close: 990 - 1490mm Max Ground Pressure on Stabilizer: 3124daN - 4.42daN/cm2 Variable Stabilization Area: 4079x3978mm (5451x2502mm) Please note: This product description and specification is based on the model most widely stocked across our network of partner stores. Alternative brands of equivalent specification may be supplied based on location and availability.
-
Product Video
-
